SyPly BIRCH Middle
Birch plywood of middle grades
The main feature of SyPly BIRCH Middle plywood is the possibility to combine different veneer grades on both sides of a plywood sheet, due to which all the aesthetic and physical-mechanical properties of the product have been preserved.
Advantages:
exceptional strength and durability
recommended for production of furniture and interior design
for treatment with paints, toning materials
Grades
SyPly BIRCH Middle
Formation of SyPly BIRCH Middle plywood grades
BB/BB , BB/CP , BB/C , CP/CP
There is the difference between grades of plywood and grades of veneer. Grades of plywood are made up of veneer grades which are used for covering. For example, plywood covered on the front side with grade B veneer and on the back side with BB veneer will have grade B/BB - the first indicates the highest grade.
View pictures of plywood by grade
Sizes
SyPly BIRCH Middle
Long grain direction on outer veneer sheets:
2440x1220 , 2500x1250
Cross grain direction on outer veneer sheets:
1220х2440 , 1250х2500
Cut-to-size:
Thickness, mm
SyPly BIRCH Middle
4.0 , 6.0 , 9.0 , 12.0 , 12.5 , 15.0 , 18.0 , 19.0 , 20.0 , 21.0 , 24.0 , 27.0 , 30.0 , 32.0 , 35.0 , 40.0
Number of layers, pcs.
Coating
SyPly BIRCH Middle
Surface
sanded
Glue type / Water resistance
WBP (increased water resistance)
Application
INTERIOR DESIGN
sound-absorbing panels
auditoriums
concert halls
wall panels, partitions
windowsills
doors
parquet boards
EXTERIOR DESIGN
facade design
balcony floors
scaffolding
roofing
gate and fence
FURNITURE PRODUCTION
facades, side and rear cabinets
case for upholstered furniture
garden and garden furniture
bathroom furniture
tables and tabletops
cabinets and shelves
kitchen furniture
shelving
children's furniture (tables, chairs, benches, cabinets, etc.)
school furniture
PROMOTIONAL PRODUCTS
souvenirs
vases, plates
children's toys
BUILDING
maintenance bridges and loading bays
outbuildings and facilities
fences
farm buildings
roofing materials
warehouses
partitions, doors
scaffolding
flooring under the floor
formwork
TRANSPORT ENGINEERING
trailers
sheathing
the doors
bodywork
the floors
In production:
trucks
shopping trailers
caravans
trolleybuses
containers
buses
trailers
campgrounds
pickups
wagons
PACKAGING
tare and packing
decorative boxes and boxes
Application
SyPly BIRCH Middle
SIZE, mm
Long grain direction:
2440x1220 , 2500x1250
Cross grain direction:
1220х2440 , 1250х2500
Size on demand
Cut-to-size is possible
Additional options: cutting of tongue and groove or half and lap
Grades
BB/BB , BB/CP , BB/C , CP/CP
THICKNESS, mm
4.0 | 6.0 | 9.0 | 12.0 | 12.5 | 15.0 | 18.0 | 19.0 | 20.0 | 21.0 | 24.0 | 27.0 | 30.0 | 32.0 | 35.0 | 40.0
Surface
sanded
Class of formaldehyde emission
Fact E0,5 (Standard E1)
Glue type / Water resistance
WBP (increased water resistance)
Humidity
5-9 %
